Name: XBD-GJ Deep Well Fire Pump
Brand: willingfluid
Price: 999.00 USD
Availability: InStock

Home Deep Well Pumps

XBD-GJ Deep Well Fire Pump

$999.00

XBD-GJ Deep Well Fire Pump is a vertical turbine fire pump designed for deep well and underground water source applications. Featuring multi-stage impellers, stable high-pressure performance and reliable continuous operation, it provides an effective firefighting water supply solution for industrial and municipal fire protection systems.

40 People are viewing this right now

XBD-GJ Deep Well Fire Pump is a vertical turbine fire pump specially designed for reliable firefighting water supply from deep wells, underground reservoirs, lakes, rivers and other water sources with low water levels. The pump adopts a vertical shaft structure with multi-stage impellers, which provides stable pressure performance and continuous water delivery under various operating conditions.

The pump is designed for applications where conventional horizontal fire pumps cannot meet suction requirements. By installing the pump body vertically into deep water sources, XBD-GJ series can achieve efficient water extraction with stable flow and high head performance. The pump can be driven by an electric motor or diesel engine, providing flexible solutions for different fire protection systems.

With its compact vertical structure, high reliability and strong adaptability, XBD-GJ Deep Well Fire Pump is widely used in industrial fire protection systems, petrochemical facilities, power plants, municipal fire networks, airports, ports and large commercial buildings where continuous and dependable firefighting water supply is required.

Model Meaning：

Features
·Vertical Turbine Structure
The vertical shaft design allows installation in deep wells and underground water sources, saving installation space and improving water intake capability.
·High Head & Stable Performance
Multi-stage impeller design provides high pressure output and stable operation for long-distance water supply and high-rise firefighting systems.
·Reliable Fire Protection Operation
Designed for emergency firefighting applications with continuous water supply capability and high operational reliability.
·Flexible Driving Options
Available with electric motor drive or diesel engine drive according to project requirements.
·Excellent Hydraulic Efficiency
Optimized impeller and guide vane structure ensures efficient hydraulic performance and reduced energy consumption.
·Strong Adaptability
Suitable for different water sources including deep wells, reservoirs, rivers and underground water systems.
·Easy Maintenance
Modular vertical structure simplifies installation, inspection and maintenance.

Parameters
Model: XBD-GJ Deep Well Fire Pump
·Pump Type: Vertical Turbine Fire Pump
·Flow Capacity: 6 L/s – 556 L/s
·Head Range: 30 m – 250 m
·Power Range: 7.5 kW – 500 kW
·Discharge Size: DN50 – DN500
·Speed: 980 / 1480 / 2960 rpm
·Drive Type: Electric Motor Drive or Diesel Engine Drive
·Pump Structure: Vertical Multi-stage Turbine Pump
·Medium: Clean Water
·Medium Temperature: ≤80℃
·Installation Type: Vertical Deep Well Installation
·Applicable Water Sources: Deep Wells, Underground ·Reservoirs, Lakes and Rivers
·Control Mode: Automatic / Manual Fire Pump Control System
·Application Standard: Designed for Fire Protection Water Supply Systems and Industrial Fire Safety Applications

Application
·Industrial plants and manufacturing facilities
·Petrochemical plants and oil & gas terminals
·Power stations and energy projects
·Airports and railway facilities
·Ports and large infrastructure projects
·Municipal fire protection networks
·Warehouses and logistics centers
·High-rise commercial buildings
·Large-scale sprinkler and hydrant fire protection systems
